briquette machine
briquette machine
1-200 tons per hour.
Suitable for charcoal, coal, coke, peat, mineral powder etc.
Ball, oval, pillow, square, rod, heart shape all available.
Briquette Machine Working Principle
The briquette machine’s main motor drive reducer via V-belt, The reducer passes through the axis and passed to the active shaft and then a pair of open gears to ensure that the two mould shafts are synchronized. Pre-press spiral press material into the middle of the mould.
Since the speed reverse rotation force the material to be pressed between the mould, The wire pressure is from small to large until the pressure on the center line of the roller reaches the maximum value. As the roller continues to rotate, the wire pressure continues to decrease and briquettes go off.
Briquette Machine Structure
- Feeding part. This part is mainly to achieve quantitative materials to ensure that the material is uniformly enter the roller.
- The transmission part, the main transmission system includes electric motor-coupling-synchronous reducer — roll.
- The molding part mainly refers to the host part, and the core part is the pressure roller.
| Model | Roller diameter (mm) | Capacity (t/h) | Motor Power (kw) | Reducer model |
|---|---|---|---|---|
| Q290 | 290 | 1-2.5 | 5.5-7.5 | ZQ350 |
| Q360 | 360 | 3-5 | 7.5-11 | ZQ350 |
| Q430 | 360 | 5-8 | 15 | ZQ400 |
| Q500 | 500 | 8-11 | 30 | ZQ650 |
| Q650 | 650 | 10-15 | 45 | ZQ750 |
| Q750 | 750 | 20-25 | 45 | ZQ750 |
| Q850 | 850 | 20-28 | 55 | ZQ860 |
| Q1000 | 1000 | 25-35 | 90 | ZQ1000 |
Why SMAT Briquette Machine so popular?
Q:How to choose suitable briquette machine?
We have engineer team specially for project solution designing, they will calculate based on your project requirement, such as the hourly capacity, input and output size, etc.
Please contact us for free project designing.
Q:Can the briquette machine be equipped with diesel engine?
We offer customized equipment. If there is no stable electricity supply, we will suggest you to use diesel engine or diesel generator. And the detailed solution can be designed per your project requirement.
Q:How can we check your machine quality?
We can have video conference with your team, thus we can show you our workshop and machine quality.
On the other hand, we accept third party inspection.
Q:How can you ensure your after sale service.
1.We have professional engineers can provide both online and on-site installation and training.
2.We have local installation team partners can provide you turn-key installation, commissioning and training.
